1 / Material :
Premium Steel (
Users can increase the productivity and get a better cutting effect with higher precision cutting rules, the machine also will enjoy the less machine-wear
2 / Size and Packing :
Size meter lengths packing coils packing
0.71*23.30*1000mm, 2PT 100PCS/box 100m/coil
0.71*23.60*1000mm, 2PT 100PCS/box 100m/coil
0.71*23.80*1000mm, 2PT 100PCS/box 100m/coil
1.07*23.80*1000mm, 3PT 70PCS/box 70m/coil
1.42*23.80*1000mm, 4PT 50PCS/box 50m/coil
3 / Body Hardness :
HRC 34~36 (soft)
HRC 37~39 (medium hard)--standard
HRC 40~42 (hard)
4 / Tip Hardness
HRC 52~56
5 / Tip Hardening Method :
High Frequency Induction, which is the most advanced technology in the world.
6 / Tip Form :
Center Bevel, Side Bevel, Long Center Bevel, Long Side Bevel
7 / Tip Type :
Shaved edge, Ground edge (42° , 52° )
8 / Application :
Die cutting cardpaper, box, carton, corrugated box and so on...
Cutting rules in coils is very suitable for auto bender
Basic Info :
Model NO : 4PT * 1.42 Rotary Rule
Shape : Notched Unnotched Curved
Cutting Material : Paper Card Corrugated Paper Pet
Delivery Lead Time : 2 Weeks
Keywords : 2PT 3PT 4PT Rotary Steel Cutting Rule
Key Words : Cutting Rule for Die Making
Types : Cutting Creasing Rules
Transport Package : Carton Box
Specification : 2PT / 3PT / 4PT
Trade Capacity
International Commercial Terms(Incoterms) : FOB, CIF, CFR
Terms of Payment : LC / T/T / PayPal / Small-amount payment
Average Lead Time : Peak season lead time : one month, Off season lead time : one month
Number of Foreign Trading Staff : 9
Export Percentage : 41%~50%
Main Markets : North America, South America, Europe, Southeast Asia/ Mideast, Africa, East Asia(Japan/ South Korea), Australia
Nearest Port : Hong Kong
